How to photograph the Moon my way and with stacked images / by Ian Timberlake

Introduction

There are a million places on the internet (probably more) that explain how to get a great photograph of the moon. Even while following tutorials and articles it was still only by trial and error that the quality of my moon shots saw significant improvement over the course of more than a year; I'm sure others can do it quicker. By now I've taken a few thousand shots of the moon... mostly because I've started to take many photographs in a row to stack into one image, more on that later.

Here is my most recent image of the moon. I will also show you a relative progression of my moon photos, from some of the earliest, all the way to this current image.

Half Moon photograph stack using many exposures and various programs.

First Photograph

The first photo I ever took of the moon with my first DSLR camera was so horrid I deleted it seconds after I took it. I set up the tripod, pointed the camera at the moon with my 18-135mm kit lens, zoomed all the way, and set the aperture wide open and the shutterspeed to 30 seconds. Don't ask me why. Of course the photo turned out to look like a white sun viewed from the Moon, instead. My cell phone did better without me doing anything. The Moon is bright.

A vast majority of articles out there will spit out the same exact exposure numbers. The cynic inside of me thinks this is a positive feedback loop of people reading an article, taking a photo, and then writing an article. The settings I read everywhere are as follows: 1/125th sec, f/11, ISO 100, manual focus, tripod, 2 second timer, 200+mm lens (I use a 400mm). Don't get me wrong, a lot of people use these settings and get great photos, but it took me a few months to realize this isn't a rule and that some of my best images were with other settings. In fact, my preferred method is different than the above.

Beginning with the commonly written settings, the first photo I took of the moon that I felt I could share with friends is the following image. I was quite proud of it but knew it was well below the quality of many images I saw online. This was taken 1 March 2017.

My first moon photo I felt I could share with friends. Taken with the most common cited exposure settings found online: 1/125th sec, f/11, ISO 100, 200+mm lens, manual focus, tripod, 2 sec timer.

The same night I also took a photo exposed for the shadow side of the Moon. These were obviously different settings because the exposure needed to be for the shaded side. Feel free to laugh.

Taken the same night as the above photo. This is an exposure for the shaded side of the moon.

Second Photograph

About two weeks later, when the above moon phased into a full moon, I tried again using more-or-less the same settings as written, deviating only slightly. Not only is the Moon out of focus, but I came to realize that a full moon doesn't express craters as well because the sunlight is hitting it directly and not casting any shadows across its surface. The result was an extremely flat, out of focus image. For fun, I decided to mark the Moon landing sites.

My second photo of the Moon that I was willing to share with friends. I have to admit, pretty embarassing but an important step in learning. I also marked the landing sites of the Apollo missions.

Third Photograph

I subscribe to SpaceWeather.com, a website that keeps track of stellar events in the present and near future. Noticing a Jupiter-Moon conjunction coming up, I tried to get them in the same photo. Here is the result. Note that there is only slight improvement on photographing the moon.

Jupiter-Moon conjunction

Experiments and Tactics for Success

This is probably the most important step, at least for me. After throwing away everything I read online, in an attempt to immitate others, I decided to start from scratch and simply ask myself what variables could lead to specific problems. I had taken hundreds of photos with more-or-less the same techniques and I had become quite frustrated. The wild west presented itself.

  • Shoot in RAW format: I shoot in RAW about 99% of the time and was using it in all the above photos, but it's worth noting.
  • Use mirror-lockup mode: This is a setting within the camera that flips up the mirror on your first press of the photo button and then takes the photo on the second press. This helps eliminate vibration in the camera that might be caused by the mirror flipping up and down when you take the photo.
  • Turn off lens stabilizer: Lens stabilizers are amazing bits of technology, but when you're in a super solid set-up, like what we're doing, the stabilizer fights itself and can over-compensate. This results in a less sharp, even blurry photo.
  • Get a sturdy tripod and get it as low to the ground as possible: I had been using my tripod extended to my standing height, which increased the risk of wobble in the wind as well as time it took for the camera to settle after touching it. I now have the legs all the way in and based out as wide as I can and I do my best to tighten and lock down every single joint. This requires sitting on the ground. Often I'll use a foam pad to keep my butt warm.
  • Find steady Earth: Find a spot that's as steady as possible, like concrete. Not a wooden deck, not hard packed dirt, and please not grass.
  • Use a laptop for focus: Maybe this isn't accessible to certain people, but I decided to move from using a corded remote shutter, to plugging my camera into my laptop and using the free EOS Utility software provided by Canon. There's also an app for your phone if you have a WiFi or NFC enabled camera. I found this absolutely crucial for achieving focus. Focusing on the Moon is harder than you think. You can either auto focus on a very distant object in the horizon and pray to the Luna Goddess that you don't so much as breath on the focus ring (some people tape it), or you set everything up, zoom in all the way, digitally zoom in if you have an LCD screen, and manually turn the ring until the edge of the Moon is sharp... both of these are obviously possible but harder than you think. The EOS Utility allows me to go full screen on my laptop and focus it one tic at a time via the utility itself. I never need to touch the camera from this point on (unless to reposition the Moon in frame).
  • Find the optimal sharpness for your lens: Every lens paired with every camera has an optimal sharpness aperture. There is an aperture size that achieves a measured result in sharpness, unique to your camera and lens. After much research online and personal testing, the optimal aperture size for my setup was between f/5.6 and f/7.1, most said f/6.3 but it's very difficult for me to see a difference in this range. But there is absolutely a difference in sharpness when compared with the often recommended f/11 when photographing the Moon.
  • High shutter speed: The faster your shutter speed, the better freeze you'll get with your subject. The Moon sweeps across your frame faster than you think so I got a double benefit when I found the optimal aperture size allowed me to have a much faster shutter speed, better freezing the Moon as it moved. Because the aperture had the most impact on in-focus sharpness, I varied the shutter speed based on what phase the Moon was in (how bright it was). On a full moon, at f/5.6, ISO 100, I was getting a properly exposed shutter speed of 1/1250th of a second, an order of magnitude faster than the recommended 1/125th sec... a far cry from the 30 second exposure on my first ever Moon photo.
  • Remove all filters: You should never use a polarizer at night, it's useless. However, I was using a UV filter on my lens as a lens protector. In the event I scratched my "lens", I could remove the filter and put a new one on. UV filters don't really do anything but they are good barriers for your expensive lenses. With that said, they aren't nearly as perfect in optics as almost all lenses so you'll get a sharper photo if you take it off.
  • Photograph the Moon high in the sky (and with zero haze): The haze bit is obvious, but if we're going to check all boxes then it must be acknowledged that the closer the Moon is to the horizon, the more atmospheric disturbance you'll see. With a very fast shutter and taking many photos, this shouldn't be a big problem.
  • Take many photos: There are always variables out of your control, or variables that you can mostly control but not always. This is why you take dozens of photos in a sitting and select the best one.
  • Image Stacking: see below

Image Stacking Specifically for the Moon

Now we're getting to the part that takes your stuff to the next level. Before attempting this, you must be getting consistently sharp photos of the Moon in one sitting using the methods above or whatever methods you find to work best for you. You must have sharp, defined edges in each image for the computer to recognize. You will need at least 100 photos of the Moon in a single night; the more the better.

I am by no means a true master of the following methods, there are astrophotographers out there that have been stacking tens of thousands of images, sometimes hundreds of thousands of images over the course of a decade. The following Windows programs are specific astrophotography tools designed for you to sharpen images of the Moon:

  1. Pipp
  2. AutoStakkert!3
  3. RegiStax6

1. PIPP

  1. In the computer file, select all the Moon photos you took (100+, the more the better) and drag them into PIPP.
  2. Check "Solar-Lunar Full Disk".
  3. Go to the "Processing Options" tab and deselect "Convert Color to Monochrome" and change the "Cropping" to a size smaller than the frame of your photo that you want all images to stack to; make sure the crop is square (unless you don't want that).
  4. Go to the "Quality Options" tab and check "Only Keep The Best Quality Frames". Once you check this the program will rank the highest quality frames (based on its algorithm) and you type in how many of the best ranked ones to use. If I imported 200 photos and chose 80 frames to keep, then it'll take the best 80 frames of the 200. The more photos you take, the higher the quality your stacked photos will be. You could take 1,000 photos and stack the top 100, which would be better than stacking the top 80 of 200.
  5. Go to the "Output Options" tab and select "Tiff" as the export format and then "Create Subdirectory" so that only exported PIPP files end up in the folder.
  6. Go to "Do Processing" and click "Start Processing". This will take a few minutes on your average computer.
  7. Once processed, click "Open Output Folder". The output folder will have named each frame by quality. If you took 200 photos and chose the top 80, you'll see that the best frame it chose is listed as "100%" and then the percentage drops from there based on assessed quality. The higher the quality of your original images, the higher the percentage will be for each frame. As a reference, all of these sorted frames that were outputted should be in the very high 90% range.

2. AutoStakkert!3

  1. Select all of the Tiff files that were outputted from PIPP and drag them into the AutoStakkert!3 window.
  2. A window should pop up to show a single reference image of your Moon. On the left, click "Place AP Grid". These points are the references the program uses when stacking. It'll analyze each of these boxes for each photo and line each of them up incredibly well.
  3. Just above that button is the "AP Size" box. The bigger the boxes, the less well it'll stack. If the boxes are too small and you have thousands of them, it could crash your computer. If your computer can handle smaller and more boxes, then do it, but you'll get a good image if you have the size set to 80-120 and it shouldn't be too hard on your computer unless it's especially slow.
  4. In the first box you dragged all of your files into, the upper right corner has something called, "Frame percentage to stack". This will now use its own algorithm to sort out the best frames. In the first of the four boxes, type in your percentage number. This percentage should be pretty high because you've already done a level of sorting in PIPP. So something like 85-90% will be good to add a little refining within AutoStakkert!3.
  5. Click, "Stack", in the lower right. This should take a minute or so.
  6. Go back to the location of all the exported frames from PIPP and there should now be a folder that starts with "AP-[something]", and inside should be a single Tiff file of the stacked images from AutoStakkert!3.

3. RegiStax6

  1. Drag the single Tiff image outputted by AutoStakkert!3 into the RegiStax6 window and check the box, "Show Full Image". This program can also align and stack but I've personally had better results with AutoStakkert!3... again, I'm not a master with these programs. We'll use RegiStax6 to sharpen the image without adding a ton of noise because it's a stacked image.
  2. Click a spot on the Moon, preferably an edge with some craters so that you can see some contrast and detail. This should highlight a specific area of the Moon as a preview to the sharpening you're about to do. This will save on processing load on your computer.
  3. Adjust the 6 layer sliders on the left to modify sharpness. Don't increase the sliders too much because a little will go a long way. You'll be able to see the result in the preview you selected.
  4. Click "Do All" button in the top left to apply your desired sharpness to the rest of the image.
  5. Click the "Save Image" button in the top left and save it where you'd like in whatever format you prefer. Note that 16-bit is better than 8-bit. If you'd like, you can now import this image into an editor of your choice, like Adobe Lightroom, if you wish to do more minor adjustments like fixing the white balance and adjusting the saturation to bring out a little bit of color. Yes, the Moon has color and it's beautiful.

Conclusion

There is a lot of information to digest in this post but it reflects the complete timeline of my progress photographing the Moon.

Remember:

  • Start at a baseline based on information you've gathered.
  • Try to eliminate every possible element that could lead to a soft/blurry/unfocused image.
  • Practice, practice, practice towards consistency so you can get quality stacks.

The most difficult photo I have ever taken is the one below, the International Space Station transiting the Moon. There will be a future post about what it took to achieve this shot.
